2015 Germany Cleaning Battery Charger 24V 10A/24V 30A
.ES-C(1200W) battery charger specification
No. | spec | Constant voltage | Constant current | Transition/ Cut-off | Weight | size | |||
|
| Lead-acid | Li-Mn | Lifepo4 | Max (A) | Lead-acid | Li | (kg) | (mm) |
1 | 12V | 14.7V | 16.8V | 14.6V | 50 | 10 | 2.5 | 4.5 | 260*175*90
|
2 | 24V | 29.4V | 29.4V | 29.2V | 35 | 6.5 | 1.65 | ||
3 | 36V | 44.1V | 42.0V | 43.8V | 20 | 4 | 1 | ||
4 | 48V | 58.8V | 54.6V | 58.4V | 18 | 3.6 | 0.9 | ||
5 | 60V | 73.5V | 75.6V | 73.0V | 15 | 3 | 0.75 | ||
6 | 72V | 88.2V | 84.0V | 87.6V | 12 | 2.4 | 0.6 | ||
Features | 1 | Full automatic transition of CC, CV and Float/cut-off | |||||||
2 | Precise limit of voltage & current, guarantee fully charged and avoid over charge | ||||||||
3 | Protections: over current, over voltage, short circuit and reverse polarity | ||||||||
4 | High Efficiency: 95%~98%, PFC: 0.96, eco-friendly | ||||||||
5 | Two LED indicators, Aluminium, elegant and reliable | ||||||||
6 | CE & ROHS Certified, Safety and High Quality | ||||||||
Note: Cut-off point for Li battery is 5% of CC, and it can be set between 3%-10%. All functions can be customized production(e.g.BMS communication,predict charge,Recharged regularly,Active power factor correction PFC) | |||||||||
Product Pictures
Structure Chart 2015 Germany Cleaning Battery Charger 24V 10A/24V 30A
.ES-C(1200W) Structure drawing
Input and Output Connectors 2015 Germany Cleaning Battery Charger 24V 10A/24V 30A
Tip
1.Products should be stored in package box when it is not used.
2.Warehouse temperature should be -40~70℃, and relative humidity is 5~95%.
3.In the warehouse, there should not be harmful gas, inflammable, explosive products,corrosive chemical products, and strong mechanical vibration, shock and strong magnetic field affection.
4.The package box should be above ground at least 20cm height, and 50cm away from wall, thermal source, and vent.
5.Under this requirement, product has 2 years of storage period, and should be rechecked when over 2 years.
Sepecification 2015 Germany Cleaning Battery Charger 24V 10A/24V 30A
Temperature | -10~45 Degree |
Hi-pot | ≥AC1500 (P to S),≥AC1500 (P to FG) |
Life Expectancy | 50,000H at 25 Degree |
Apply to | Cleaning Equipment |
In Use
Why Choose Our Company?
Company Capacity
Trade Capacity | North America : 7.69% South America : 7.69% |
Production Capacity | Factory Size : Below 1,000 square meters No. of Production Lines : Above 10 |
R&D Capacity | No. of R&D Staff : 5 - 10 People |
Our Service
1.Your inquiry related to our products or prices will be replied in 24hours. Meanwhile, we will solve any problems or worries you have before taking the order.(Pre-sale)
2.We will track the products all the time and offer enough long warranty.(After-sale)
3.OEM is accepted
Business Terms
1.Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery
2.Accepted Payment Currency: USD, EUR, CNY
3.Accepted Payment Type: T/T, PayPal, Western Union, bank transfer 2015 Germany Cleaning Battery Charger 24V 10A/24V 30A
Our Company
Any other models with different voltage and current is ok for us! I'm always here for you! More detail about the charger?Please click here!
